Nex3D

Introducing the new Nexa3D Printer with unmatched speed & size

Six times the speed & 2.5 times the volume of other comparable 3D printers.
Continuously print up to 16 liters of parts at speeds of up to 1 inch per 2.5 minutes (1 Z-centimeter per minute).

Nexa3D Materials PDF Download
Get More Info on Nexa3D Now
Print Tech Continuous LSPc
Light Source Structured Light Matrix
XY Scanning 0.0029 inches (75 microns)
Build Area 11×6.5×15.74 inch (280x165x400 mm)
Z Resolution 0.0019″/0.0039″/0.0078″ (50/100/200 microns)
Z Coordinate Z-axis and Vat
UI Predictive and Prescriptive
Interface USB Cable/USB Drive/Ethernet/WIFI
Input File Format .stl, .3ws, .3wn, .STEP
Materials xABS-HT-Orange, xGPP-Translucent, xGPP-Gray, xGPP-Blue

2.5x Larger Build Volume

The NXE 400 features more than double the build volume compared to currently available technologies, allowing for much larger parts, higher part throughput, and ultimately lower part cost, all with the higher-resolution pixels (75 µm) and isotropic prints.

Manufacturing Ready + Modular Design

In addition to our highly reliable LSPc technology, the NXE 400 is crafted to be completely modular in design for easily interchangeable parts and technology upgrades eliminating hardware obsolescence.

Next-Gen Software + Predictive Service

Nexa3D’s internally developed intelligent software connects our hardware and materials together into a powerful, user friendly system while providing a new era of predictive and prescriptive service. It’s as simple as pressing CRTL+P.

Intelligent Part Washer

Improve part quality and reduce labor with the Smart Part Washer to get fully functional parts in minutes with injection molding quality.

Maximize Part Quality and Yield

The NXE 400 is the next scalable manufacturing solution with additional washing and curing units capable of handling even the largest 16L parts on a single tray making the NXE 400 the most advanced printing solution in its class.

Smart and Connected

Our next-generation internally developed software and connected senor system provides intelligent, part-to-part curated washing protocols, part traceability through a digital twin, and automatic software updates to continuously improve the printing experience.

Finally, Manufacturing at Scale

The Intelligent Part Washer & Curing units deliver fast, simple, and repeatable part washing & curing, finally unlocking the full potential of additive manufacturing at scale and environmental stewardship.

Washing + Curing Station

The Nexa3D post-processing units are designed to optimize the washing and curing process of the parts printed on the NEXA3D printers.

Holding up to 16L of part volume the washing unit will automatically decide on the length of the washing process while the curing station will decide on the intensity and light distribution based on part geometry and part distribution on the build plate.

With combined wash and cure time as fast as 10 minutes these are the ideal units to complete the print process.
